Hanwha Vision WRR-P-E201W-48TB

Overview

The Hanwha Vision WRR-P-E201W-48TB is a rack-mount recording server designed to support video surveillance systems with high reliability and ease of use. It comes pre-installed with Wisenet WAVE video management software and includes four professional licenses, allowing you to start recording immediately. Equipped with 48TB of raw storage capacity, it offers about 36TB of usable space in a RAID 5 configuration, suitable for storing weeks or months of high-definition footage depending on your retention needs.

Powered by an Intel Xeon E2356G processor and 16GB of RAM, this server handles up to 470 Mbps of recording throughput, supporting dozens of concurrent camera streams without dropped frames. The operating system runs on dual 480GB solid-state drives in RAID 1, ensuring continuous operation even if one drive fails. With two 1GbE network ports, HDMI and VGA outputs, and redundant 450W power supplies, it is built for dependable performance in demanding environments.

Key features

• Pre-installed Wisenet WAVE software with four professional licenses for immediate deployment and simplified setup
• RAID 5 storage array providing 36TB of usable space to securely store extensive video footage
• Intel Xeon E2356G processor combined with 16GB RAM to maintain smooth operation and handle multiple video streams simultaneously
• Dual 480GB SSDs in RAID 1 protect the operating system, minimizing downtime and data loss risks
• Hardware RAID controller with 512MB cache supports multiple RAID levels for flexible storage management
• Two 1GbE network ports enable reliable connections to camera networks and client workstations
• HDMI and VGA outputs allow direct connection to local monitors for on-site viewing and maintenance
• Redundant 450W power supplies enhance system resilience and reduce the chance of unexpected outages
• Includes rack-mount rail kit, keyboard, and mouse for quick and convenient installation in standard rack cabinets

Key specs

• Processor: Intel Xeon E2356G
• Memory: 16GB RAM
• Storage: 48TB raw capacity with 36TB usable in RAID 5 configuration
• Operating system drives: Dual 480GB SSDs in RAID 1
• Recording throughput: Up to 470 Mbps
• Network interfaces: Two 1GbE ports
• Video outputs: HDMI and VGA
• Power supplies: Redundant 450W units

Connectivity and compatibility

This server offers two 1GbE Ethernet ports that provide stable and fast connections to both camera networks and client workstations, ensuring smooth data flow and remote access. The inclusion of HDMI and VGA outputs makes it easy to connect a local monitor for direct video playback, system monitoring, or configuration without needing additional equipment. Its compatibility with Wisenet WAVE software and professional licenses supports a wide range of IP cameras and surveillance setups.

Installation and setup

The Hanwha Vision WRR-P-E201W-48TB arrives ready to install with a rack-mount rail kit included, along with a keyboard and mouse to facilitate initial configuration. The pre-installed Wisenet WAVE software and included licenses eliminate the need for complex software installation, allowing security teams or integrators to power on the server, connect cameras, and begin recording quickly. Redundant power supplies and RAID configurations add layers of protection that reduce maintenance interruptions.

Ideal uses and environments

This recording server is well suited to mid-sized corporate environments, retail stores, schools, and healthcare facilities that require reliable local video recording with minimal administrative overhead. Its robust hardware and storage capacity make it a strong choice for security teams managing multiple high-definition camera streams who need consistent performance and data protection. The system’s resilience features also make it a practical option for installations where uptime is critical.
