ADJ MDF200

Overview

The ADJ MDF200 is a modular LED dance floor panel designed to transform any stage, club, or event space into a vibrant and dynamic visual experience. Measuring 23.62 by 23.62 inches with a tempered glass surface, it features RGB 3-in-1 LEDs that deliver bright and even color across the entire panel. Its sturdy construction supports up to 61.5 pounds per square foot, making it suitable for dancers, performers, and display pieces alike. Despite its robust build, each panel weighs just 26.57 pounds and stands 2.76 inches tall, allowing for easy handling and installation.

Key features

• RGB 3-in-1 LED light source provides a wide range of rich colors for mood lighting or energetic effects
• Magnetic locking system aligns panels precisely while passing power and data without cables, speeding up setup and reducing clutter
• Tempered glass surface offers durability and supports heavy loads, ensuring safety for performers and equipment
• DMX512 control via standard 3-pin XLR input allows flexible programming from simple fades to complex pixel effects
• Low power consumption of 15 watts at 24 volts DC keeps energy use efficient during extended events
• Lightweight and slim design makes transport and assembly straightforward for mobile DJs and production teams

Key specs

• Panel dimensions: 23.62 x 23.62 x 2.76 inches
• Weight: 26.57 pounds per panel
• Load capacity: 61.5 pounds per square foot
• Light source: RGB 3-in-1 LEDs
• Power consumption: 15 watts at 24 volts DC
• Control input: DMX512 via 3-pin XLR

Connectivity and compatibility

The panel integrates seamlessly into professional lighting setups through its DMX512 control input, using a standard 3-pin XLR connector. This compatibility allows it to work with a wide range of lighting consoles and controllers, enabling precise color and effect programming. The magnetic locking system not only secures panels together but also passes power and data through the connections, eliminating the need for additional cables and simplifying the overall wiring.

Ideal uses and environments

This LED dance floor panel is well suited for venues that require a visually engaging floor surface, such as nightclubs, hotel ballrooms, and retail spaces. It also fits mobile setups for DJs and production companies who need quick assembly and reliable performance. The panel’s durable tempered glass and high load capacity make it a strong choice for environments where performers or heavy display items will be present. Its low power draw and modular design support both temporary installations and permanent setups that run nightly.
