Axis 01768-001

Overview

The Axis 01768-001 is a two-megapixel network box camera designed to provide reliable, high-definition surveillance with minimal setup complexity. It features a 1/3-inch progressive scan RGB CMOS sensor that captures video at 1920 × 1080 resolution and 30 frames per second, delivering clear and detailed footage. The camera’s Lightfinder technology combined with forensic wide dynamic range ensures accurate color reproduction and detail retention even in low-light or challenging lighting conditions.

Equipped with a 3–10.5 mm varifocal lens, it offers a flexible horizontal field of view ranging from 90 to 33 degrees, allowing you to adjust from wide-angle monitoring to focused zoom on specific areas. The CS mount lens system also supports easy lens replacement to adapt to changing surveillance needs. Installation is streamlined with Power over Ethernet, enabling data and power delivery through a single cable, while an integrated microphone adds synchronized audio to video recordings.

Key features

• Lightfinder technology and forensic wide dynamic range maintain image quality in dim or mixed lighting environments, ensuring reliable surveillance day and night.
• Varifocal 3–10.5 mm lens allows flexible framing from wide views to zoomed-in details, adaptable to various monitoring scenarios.
• CS mount lens system supports easy swapping of lenses to suit different distances or fields of view without replacing the entire camera.
• Integrated microphone captures synchronized audio, enhancing situational awareness and evidence collection.
• Power over Ethernet simplifies installation by combining power and data transmission into a single cable, reducing clutter and setup time.
• Supports efficient video streaming with H.265, H.264, and MJPEG codecs to optimize bandwidth usage without sacrificing image quality.
• MicroSD card slot enables local storage for edge recording or backup, increasing system resilience and reducing dependency on network storage.
• Compliance with ONVIF Profiles G, S, and T ensures broad compatibility with most video management systems, facilitating integration into existing setups.
• Signed firmware and secure boot protect the camera from unauthorized code, enhancing security and maintaining system integrity over time.

Key specs

• Resolution: 1920 × 1080 pixels (Full HD)
• Frame rate: 30 frames per second
• Image sensor: 1/3-inch progressive scan RGB CMOS
• Lens: 3–10.5 mm varifocal with CS mount
• Horizontal field of view: 90° to 33°
• Video compression: H.265, H.264, MJPEG
• Audio: Built-in microphone
• Power: Power over Ethernet (PoE)
• Storage: microSD card slot for local recording
• Security: Signed firmware and secure boot
• Standards: ONVIF Profiles G, S, and T

Connectivity and compatibility

This camera integrates smoothly into a variety of surveillance systems thanks to its support for ONVIF Profiles G, S, and T, which cover recording, streaming, and device discovery protocols. The Power over Ethernet capability reduces installation complexity by delivering both power and data through a single cable, making it suitable for locations where running multiple cables is impractical. The microSD slot provides an option for local storage, which can be critical for maintaining footage during network interruptions.

Ideal uses and environments

The Axis 01768-001 is well suited for retail stores, offices, classrooms, and reception areas where dependable video quality and flexible viewing angles are essential. Its low-light performance and wide dynamic range make it effective for monitoring areas with varying lighting conditions, such as loading docks at night or brightly lit lobbies during the day. This camera fits well in setups that require scalable deployment with straightforward installation and reliable security features.
