Chief LCB2X1U

Overview

The Chief LCB2X1U is a ceiling mount designed to hold two flat-panel displays back to back, ideal for locations where wall mounting is not an option. It supports screens ranging from 40 to 55 inches, with the option to extend up to 65 inches using additional brackets. Each display can weigh up to 100 pounds, making it suitable for a wide range of commercial-grade panels. This mount is perfect for creating clear, professional menu boards or digital signage in busy environments such as restaurants, retail spaces, and corporate lobbies.

Key features

• Back-to-back 2 x 1 layout allows dual-sided viewing for overhead menu boards or signage.
• Centris tilt technology enables easy adjustment of the viewing angle from 5 degrees above level to 20 degrees below, reducing glare and improving sight lines.
• 360-degree swivel and ±3-degree roll adjustments provide precise alignment without removing the displays.
• Single horizontal extrusion keeps both screens perfectly aligned and square to each other.
• Tool-free engagement system speeds up installation and maintenance, minimizing downtime.
• Padlock compatibility adds theft deterrence in public or high-traffic areas.
• Compatible with standard or pinned CPA extension columns, allowing customization of drop length and mounting style.

Key specs

• Display size support: 40 to 55 inches (expandable to 65 inches with optional brackets)
• Weight capacity: 100 pounds per display
• Tilt range: +5° to -20°
• Swivel: 360 degrees
• Roll adjustment: ±3 degrees
• Mounting style: Ceiling mount (ceiling plate and extension column sold separately)
• Color: Black

Installation and setup

The mount is designed for quick and straightforward installation on site. Its tool-free engagement system secures the rails without the need for additional tools, making setup and maintenance efficient. The single horizontal extrusion ensures both displays remain perfectly aligned, simplifying the installation process. Since the ceiling plate and extension column are sold separately, you can select the exact drop length and mounting style that best fits your environment.

Ideal uses and environments

This mount is well suited to environments where dual-sided digital signage or menu boards are needed but wall space is limited or unavailable. It works effectively in restaurants, retail floors, corporate lobbies, and other busy areas where clear information must be visible from multiple directions. The sturdy design and high weight capacity accommodate commercial-grade displays, making it a strong choice for professional installations requiring reliable and adjustable mounting solutions.
