Chief LCM3X1U

Overview

The Chief LCM3X1U is a ceiling-mountable menu board system designed to hold three displays side by side, supporting screen sizes from 40 to 55 inches. It is ideal for environments where wall space is limited, such as quick-service restaurants, airports, and retail locations. The mount allows easy installation and adjustment, with features that ensure the displays remain perfectly aligned and aimed toward the intended audience.

Key features

• Holds three displays ranging from 40 to 55 inches, with expandability up to 65 inches using optional FCAX brackets for larger setups
• Supports up to 125 pounds per screen, accommodating a wide range of commercial displays
• Tool-free screen engagement enables quick installation and effortless service without the need for additional tools
• Centris tilt adjustment offers a range of +5 degrees forward and -20 degrees backward, allowing precise viewing angles
• Micro leveling adjustment of ±3 degrees keeps the displays perfectly even, even on uneven ceilings
• Full 360-degree swivel capability lets you aim the entire array toward customers or visitors for optimal visibility
• Compatible with standard 1.5-inch NPT and CPA pinned ceiling systems, ensuring broad installation options
• Padlock-ready design provides an extra layer of security to deter tampering in public spaces

Key specs

• Display size compatibility: 40 to 55 inches (expandable to 65 inches with optional brackets)
• Weight capacity: up to 125 pounds per display
• Tilt adjustment range: +5 degrees forward, -20 degrees backward
• Micro leveling adjustment: ±3 degrees
• Swivel range: 360 degrees
• Ceiling system compatibility: 1.5-inch NPT and CPA pinned
• UL listed for safety compliance

Installation and setup

Installation begins with securing the ceiling plate and extension column, after which each display clicks into place without requiring tools. This design simplifies both initial setup and future maintenance. The mount’s micro leveling feature compensates for uneven ceilings, ensuring a straight and professional appearance. Its compatibility with common ceiling systems makes it adaptable to a variety of commercial spaces.

Ideal uses and environments

This mount is well suited to venues that rely on clear, visible digital signage but lack convenient wall space. It works effectively in quick-service restaurants for menu boards, airports for flight information displays, retail chains for promotional content, and lobbies or terminals where multiple screens need to be grouped. Its secure, adjustable design supports dynamic environments where displays may need frequent repositioning or expansion.
