Lenovo 7D7QA020NA

Overview

The Lenovo 7D7QA020NA is a rack-mountable barebone server designed to deliver reliable and scalable computing power in a compact 1U form factor. Equipped with an Intel Xeon E-2378 processor featuring 8 cores and a base clock of 2.6 GHz (boosting up to 4.8 GHz), along with 16 GB of DDR4 ECC memory, this server provides a solid foundation for a variety of business workloads. Its flexible storage options and robust networking capabilities make it well suited for virtualization, web hosting, backup, and point-of-sale applications in small to midsize businesses or branch offices.

Key features

• Processor with 8 cores and high boost clock speeds to handle demanding multitasking and server applications efficiently
• 16 GB of error-correcting DDR4 memory installed to enhance data integrity and system stability, with room to expand up to 128 GB
• Eight front-accessible 2.5-inch hot-swap drive bays allowing customized storage configurations without downtime
• Internal M.2 slot available for a fast boot drive that preserves front bay capacity for additional storage
• Dual Gigabit Ethernet ports powered by Broadcom BCM5720, supporting PXE boot and NIC teaming for network flexibility and redundancy
• Multiple PCIe 4.0 expansion slots to add RAID controllers, network cards, or GPUs, enabling future-proof upgrades
• Lenovo XClarity Controller provides comprehensive remote management, including browser-based monitoring and alerting, reducing the need for on-site intervention
• Energy-efficient 450 W 80 Plus Platinum power supply combined with ENERGY STAR 3.0 and EPEAT Bronze certifications to help lower operational costs
• Friction rail kit included for quick and secure installation in standard server racks, simplifying deployment

Key specs

• Processor: Intel Xeon E-2378, 8 cores, 2.6 GHz base, up to 4.8 GHz boost
• Memory: 16 GB DDR4 ECC, expandable to 128 GB
• Drive bays: Eight 2.5-inch hot-swap bays (no drives included)
• Storage expansion: One internal M.2 slot
• Networking: Dual Gigabit Ethernet ports with Broadcom BCM5720 controller
• Expansion slots: Multiple PCIe 4.0 slots
• Power supply: 450 W 80 Plus Platinum certified
• Certifications: ENERGY STAR 3.0, EPEAT Bronze
• Form factor: 1U rack-mountable

Connectivity and compatibility

This server integrates seamlessly into existing IT environments with its dual Gigabit Ethernet ports that support PXE boot for network-based startup and NIC teaming for enhanced bandwidth and failover. The PCIe 4.0 slots allow installation of a wide range of expansion cards, including RAID controllers and network adapters, ensuring compatibility with evolving infrastructure needs. The internal M.2 slot offers a high-speed option for boot drives without sacrificing front-accessible storage bays.

Installation and setup

The included friction rail kit simplifies mounting the server into standard 19-inch racks, reducing installation time and effort. Lenovo’s XClarity Controller enables out-of-band management, allowing IT administrators to monitor system health, perform remote diagnostics, and manage alerts through a web interface. This reduces the need for physical access and helps maintain uptime in distributed or remote locations.

Ideal uses and environments

This server is a strong choice for small to midsize businesses, branch offices, and edge computing sites that require dependable performance for virtualization, file serving, web hosting, or backup tasks. Its flexible storage options and expansion capabilities make it adaptable to growing workloads, while energy-efficient components help control operating costs. IT teams looking for a compact, manageable server with room to grow will find this model well suited to their needs.
