APC 2G Switched ZeroU 20A 208V/230V 8-Outlets Rack Power Distribution Unit

The APC AP8958 is a switched rack power distribution unit built for data centers, server rooms, and network closets that need dependable power delivery with precise control. It slips into the vertical channel of a standard cabinet without consuming any rack units, yet it still brings eight IEC outlets to the back of the rack.

Seven C13 receptacles and one C19 receptacle share a single 20-amp circuit at 208 volts, or 16 amps at 230 volts. Because each outlet can be switched on its own, you can reboot unresponsive hardware from a browser, stagger equipment startup after maintenance, or cut power to unused devices to trim energy costs—all without a site visit.

The PDU measures current, voltage, and power in real time and shows the readings through a secure web interface. User-set thresholds trigger alarms before a circuit reaches its limit, helping you guard against overloads and plan capacity with confidence. Support for SNMP and Telnet lets you fold the unit into existing monitoring platforms, and full compatibility with APC’s centralized management software streamlines fleet administration.

A built-in port accepts an optional temperature and humidity probe, so you can keep an eye on environmental conditions in the same dashboard you use for power. The metal housing is engineered for long service life, and the two-year warranty adds an extra layer of peace of mind for critical installations.

• ZeroU design that mounts vertically and preserves rack space
• Eight outlets: seven IEC C13 and one IEC C19 for mixed equipment
• Rated for 20 amps at 208 volts or 16 amps at 230 volts
• Individual outlet switching for remote reboot, power sequencing, and energy savings
• Real-time measurement of current, voltage, and power with configurable alarms
• Secure access through Web, SNMP, or Telnet; integrates with APC centralized management
• Port for optional temperature and humidity sensor
• Two-year manufacturer warranty
